uncoiler motor: 490 kW
Main drive motor: 4,100 kW (1 unit)
Left and right coiler motors: 1,350 kW each (2 units)
Rolling force: 1,500 tons
Rolling speed: 500–1,000 m/min
Work roll dimensions: φ73.5 × 1,450 mm
First intermediate roll dimensions: φ105 × 1,650 mm
Second intermediate roll (i.e., drive roll) dimensions: φ176 × 1,450 mm
Backup roll dimensions: φ176 × 1,385 mm

Finished product thickness (minimum): 0.12mm
Material width range: 700–1,250 mm
Incoming raw material thickness range: 0.35–3.1 mm

Material:Carbon steel Q235, thickness or speed is different based on different material

last operating date: 2024
